legering 17-4ph / 1.4542 skruer med hylsehylser

Hjem » Produkter » Olje og gassfester » legering 17-4ph / 1.4542 skruer med hylsehylser

NO.112-17-4PH sekskantskruebolter 1.4568

spesifikasjoner

1.stainless steel alloy fastener 17-4PH bolts
2.grarnteed quality
3.reasonable price
4. omgående levering
5.ISO 9001:200

Product Detail

Gjenstandsnavn	Stainles Steel Alloy Fastener 17-4PH Bolts
Materiale	1. Stainless steel: 17-4PH, 254, 321, 904L, A-286, B8, B8C, B8M etc. 2. Super duplex stainless steel: 2205, 2507, S31803, S32750, S32760 etc. 3. Special alloy: Titan: Gr2, Gr5 Monel: 400, K-500 Zirkonium: 702, 705 Nimonic: 75, 80A, 90 Nikkellegering: 20, 28, 200, 201 Inconel: 600, 601, 625, 718, X-750 Hastelloy: B-2, B-3, C-22, C-276, X Incoloy: 800, 800H, 800HT, 825, 901, 925
Standard	DIN912,931,933,975 etc
Styrkegrad	4.8-12.9, A2-70, A4-80 etc.
Lengde	6mm-500mm
Størrelse	M4-M100 (1/4-4 inch)
Kategori	Hex bolt, studbolt, thread rod etc.
Overflatebehandling	Zn-plated, Ni-plated, Passivated, tin-plated, Sandblast and Anodize, Chromate, Polish, Eletro Paint, Chrome plated etc.
Varmebehandling	Tempering, Hardening, Spheroidizing, Stress Relieving

Gjenstandsnavn

Stainles Steel Alloy Fastener 17-4PH Bolts

Materiale

1. Stainless steel: 17-4PH, 254, 321, 904L, A-286, B8, B8C, B8M etc.

2. Super duplex stainless steel: 2205, 2507, S31803, S32750, S32760 etc.

3. Special alloy:

Titan: Gr2, Gr5

Monel: 400, K-500

Zirkonium: 702, 705

Nimonic: 75, 80A, 90

Nikkellegering: 20, 28, 200, 201

Inconel: 600, 601, 625, 718, X-750

Hastelloy: B-2, B-3, C-22, C-276, X

Incoloy: 800, 800H, 800HT, 825, 901, 925

Standard

DIN912,931,933,975 etc

Styrkegrad

4.8-12.9, A2-70, A4-80 etc.

Lengde

6mm-500mm

Størrelse

M4-M100 (1/4-4 inch)

Kategori

Hex bolt, studbolt, thread rod etc.

Overflatebehandling

Zn-plated, Ni-plated, Passivated, tin-plated, Sandblast and Anodize, Chromate, Polish, Eletro Paint, Chrome plated etc.

Varmebehandling

Tempering, Hardening, Spheroidizing, Stress Relieving

2. Materiell introduksjon

17-4PH / ASTM S17400

Steel 17-4 PH is a martensitic precipitation-hardening stainless steel that provides an outstanding combination of high strength, good corrosion resistance, good mechanical properties at temperatures up to 600°F(316°C), good toughness in both base metal and welds, and short-time, low-temperature heat treatments that minimize warpage and scaling.

2.1 The characteristics of 17-4PH:

(1) Formability

(2) Easy to adjust the level of intensity

(3) Good attenuation property

(4) Resistance to corrosion fatigue

(5) Strong anti-drop performance

2.2 The applications of 17-4PH:

(1) Offshore (foils, helicopter deck platforms, etc.)

(2) Food industry

(3) Pulp and paper industry

(4) Aerospace (turbine blades, etc.)

(5) Nuclear waste cask

2.3 Chemical Composition,%

C	Mn	P	S	Si	Cr
0.07max	1.0max	0.04max	0.03max	1.0max	15.0-17.5

Ni	Cu	Nb + Ta
3.0-5.0	3.0-5.0	0.15-0.45

Rask informasjon

Opprinnelsessted: Jiangsu Kina (fastlandet)
Merkenavn: HPF, QFC
Lengde: 6mm-500mm
Size: M4-M100(1/4-4 inch)
Standard: DIN 931,933,975 etc.
Alloy steel: 17-4PH/ASTM 17400
Kontroll: EN 10204 3.1 sertifikat
Karakter: 4,8-12,9, A2-70, A4-80 osv.
Packing: carbon,pallet,wooden case etc.
Transport: Sjøfrakt eller lufttransport
Material: Carbon steel,stainless steel, alloy steel etc.
Offer term: FOB Shanghai(according to custom
